SEBM Working Principle
Selective Electron Beam Melting (SEBM) is an additive manufacturing technology that uses high-energy electron beams as energy source to manufacture solid components in a high vacuum environment by melting metal powders layer by layer. The principle is that the electron beam quickly scans and melts the pre-laid spherical metal powders on the bottom plate according to the planned path. After completing a layer of scanning and melting, the workbench descends to a certain height and a new powder layer is laid. The electron beam scans and melts again according to the planned path, and this pro cess is repeated layer by layer, so that completing the manufacturing of metal parts from 2D to 3D.
SEBM Advantages
  • High energy absorption conversion rate and fast forming speed
  • High electron beam power can form refractory metals
  • Selecting coarser particle size powder as raw materials reduces the overall cost of parts
  • High powder bed temperature is suitable to form brittle and easily cracked materials with small internal stress of parts, less dependence on support and no subsequent heat treatment
  • Purer parts are formed in vacuum environment
  • Strong electron beam penetration ability, deeper molten pool and denser formed parts
Why choosing Sailong SEBM
  • Focused on R&D of metal 3D printing for over 20 years
  • The first commercial SEBM equipment launched in China
  • The market share of SEBM products ranks first in China
  • Full series of solution provider in metal 3D printing
  • The first clinical application of SEBM tantalum implant in the world
  • SEBM equipment and process technology with independent intellectual property right
  • Single electron gun with maximum power 6kW and build size 400x400x400mm
